| Raw Material Diameter | Maximum 6.0 mm (0.236”) [Guide tube clearance: 7 mm (0.280)] |
|---|---|
| Reel Diameter | Maximum 457 mm (18”) |
| Reel Width | Maximum 305 mm (12”) |
| Spool Weight | Maximum 20 kg (44 lbs.) |
| Pulling Speed | 0.0 – 1.8 m/s (0.0 – 5.9 ft/s) |
| Accumulator Storage Capacity | 0.90 m (2.8 ft) |
| Motor | 1/8 HP DC |
| Power Supply | 100, 120, 220, 240 VAC; 50 – 60 Hz/120 VA |
| Dimensions (L x W x H) | Without cable reel holder: 457 x 419 x 500 mm (17.9 x 16.4 x 19.6”) With cable reel holder: 785 x 419 x 500 mm (30.9 x 16.4 x 19.6”) |
| Weight | 17 kg (38 lbs.) |
| CE-Conformity | The PreFeeder 1100 fully complies with all CE and EMC equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility. |
| Important Note | Schleuniger recommends that wire samples be submitted in cases where there is doubt as to the processing capabilities of a particular machine. |
De-Reeling Systems
PreFeeder 1100
The PreFeeder 1100 is a solid and reliable benchtop, electric prefeeding machine for cable reels up to 20 kg (44.4 lbs.) and 457 mm (18″) in diameter. This low-cost unit is ideal for feeding wires and cables off small to medium sized spools.
