| Wire outer diameter | 0.25 – 5.5 mm |
|---|---|
| Wire cross section | 0.03 – 6 mm² |
| Strip length | 0.1 – 43 mm |
| Increment of strip length | 0.1 mm |
| Pull-off length | 0.1 – 22 mm |
| Break-out length min. | 10 mm |
| Insulation material | PVC, PUR, rubber, Teflon, Tefzel, Kapton, etc. |
| Blade | 2 blades linear, horizontal, special blades |
| Incision diameter increment | 0.01 mm |
| Gripping force | programmable |
| Piece output max. | 2800 pcs/h |
| Noise level | <70 dB |
| Electrical connection | 100/115 VAC, 230/240 VAC, 65 W, 50/60 Hz |
| Compressed-air connection | 5–7 bar |
| Compressed-air quality | Dry, filtered (10 µm), oil-free |
| Weight | 9.4 kg |
| Dimensions (L × W × H) | 390 × 130 × 280 mm |
| Temperature operation | 5 – 40 °C |
| Cycle time | 0.35 sec |
| Article library | 1,000 cables |
| Data interface | Foot pedal, USB "Host" |
| User interface | color touch panel |
| Trigger | Automatic trigger sensor or optional foot pedal |
| Options | Foot pedal, special clamping jaws, air jet |
| CE conformity | Fully complies with all CE and EMC equipment guidelines for mechanical and electrical safety and electromagnetic compatibility. |
UniStrip 2550
The programmable UniStrip 2550 strips wires ranging in size from 0.03 – 6 mm² (32 – 10 AWG) and jacketed cables up to 5.5 mm (0.22”) in diameter.
The UniStrip 2550 offers high precision and flexibility with V-blades, which work for most wires without the need for blade changes. The machine can also be equipped with radius, die, or flat blades, which are used for difficult-to-strip insulations such as Teflon, Kapton, and Kynar, typically used in the military and aerospace market. Using the color touchscreen or barcode scanner, the operator selects the desired wire size from the preprogrammed library, and all parameters (cutting diameter, clamping pressure, blade way back, etc.) are automatically set. The operator can edit the stripping and pull-off lengths as required. A very sensitive trigger sensor ensures high precision even with small, flexible wires. While processing, the operator has a clear view of the entire working area.
