| Machine type | Benchtop machine |
|---|---|
| Current | No |
| Control box | No |
| Pneumatics | Yes |
| Width | 350 mm |
| Dimensions/height | 550 mm |
| Dimensions/depth | 420 mm |
| Total recommended space requirement (width x depth) | 550 x 1420 mm |
| Weight | 15 kg |
| Recommended operating pressure ±0.5bar/7.25psi | 6 bar |
| Number of tape layers/bundling, min. | einstellbar über Bandlänge |
| Number of tape layers/bundling, max. | einstellbar über Bandlänge |
| Bundle diameter, min. | KTB 19 P: 3 mm / KTB 38 P: 3 mm / KTB 50 P: 3 mm / KTB 40/30 P: 15 mm |
| Bundle diameter, max. | KTB 19 P: 16 mm / KTB 38 P: 16 mm / KTB 50 P: 16 mm / KTB 40/30 P: 35 mm |
| Diameter detection | No |
| Integration into welding table | No |
| Device interface (USB) | No |
| Network connection | No |
| MES capable | No |
| Tape end sensor | No |
| Ejector | No |
| Oiler (for the blade) | Yes |
| Tape pull-off support | No |
| Tape pull-off | Yes |
| Tape width, min. | KTB19P: 9 mm / KTB 38 P: 19 mm / KTB 50 P: 38 mm / KTB 40/30 P: 19 mm |
| Tape width, max. | KTB19P: 19 mm / KTB 38 P: 38 mm / KTB 50 P: 50 mm / KTB 40/30 P: 30 mm |
| Tape roller outer diameter, max. | 160 mm |
| Ambient temperature max. | 40 °C |
| Ambient temperature min. | 10 °C |
| Humidity, non-condensing | 5 – 95 % |
KTB 50 P
The pneumatic bundler KTB P, a versatile machine for spot taping, marking, finishing, and insulating, is assembled according to your requirements for tape width and bundle diameter.
The KTB 50 P compressed air-driven spot taping machine offers full power without electricity for the tying of wire harnesses and the fixing and marking of cables. The efficient, low-wear cutting blade system, the sturdy design, and the pneumatic drive make this a low-maintenance machine. In addition, up to four layers of adhesive tape can be set, and material costs of up to 80% can be saved compared to shrink tubing or caps. The machine requires a minimum of space due to the compactly installed components. The pneumatic connection is located directly on the device, eliminating the need for a separate control cabinet. All adjustments are made directly on the machine, facilitating operation and maintenance.
No power connection required
KTB 50 E Plus is a versatile and robust machine with a purely pneumatic operation. The air pressure connection is located directly on the unit.
Dependable and efficient spot taping technology
The pneumatic bundler is characterized by speed and reliability. It reduces production time by up to 50% compared to manual processing.
Minimal maintenance required
KTB P is equipped with a self-oiling blade and has a low-maintenance design. All maintenance activities can be carried out by operators with limited technical knowledge.
Flexible as a standalone or for fully automated processes
Due to its efficiency and reliability, the pneumatic bundler is ideally suited for integration into fully automated processes.
