| Wire length/standard mode | 0.1 mm (0.004”) – 999‘999 mm (39,370“) |
|---|---|
| Wire outer diameter range | 0.032 – 0.47 in |
| Conductor cross section | Stranded Wire Max. 16 mm² (6 AWG) Solid Wire Max. 6 mm² (10 AWG) |
| Options | Air Jet Kit, Carbide Blades, Quadruple Cable Guides, Special Cable Guides |
| Interfaces | Standard: Prefeeder, Hotstamp, RS232, Foot pedal Optional: Post-feed interface (CableCoiler 500, CableCoiler 1450 and inkjet) |
| Raw material diameter max. | 12 mm |
| Wire cross section | 0.14 – 16 mm² |
| CE conformity | The EcoCut 3300 fully complies with all CE and EMC equipment guidelines relative to mechanical and electrical safety and electromagnetic compatibility. |
| Length increment | 0.1 mm |
| Feed rate | >= 1.60 m/s |
| Raw material width max. | 100 mm |
| Wire outer diameter min. | 0.8 mm |
| Wire length max. | 999999 mm |
| Wire outer diameter max. | 12 mm |
| Wire cross section min. | 0.14 mm² |
| Wire cross section max. | 16 mm² |
| Sequence processing (number of wires) | no |
| Length accuracy | Repetition accuracy: ± (0.2% + 1.0) |
| Drive system | Roller |
| Noise level | <70 dB |
| Electrical connection | 100VAC to 240VAC, 50/60Hz |
| Recommended operating pressure | 6 bar |
| Weight | 22 kg |
| Dimensions/length | 460 mm |
| Dimensions/width | 270 mm |
| Dimensions/height | 270 mm |
| Processing outside the specifications | Processing outside the specifications upon request. In case of doubt, we will be happy to provide processing samples for your wires. |
EcoCut 3300
The cutting machine EcoCut 3300 processes wire, cable, tubing, and ribbon up to 16 mm² (6 AWG), cuts round material up to 12 mm (0.47″), and flat material up to 100 mm (3.94″).
The EcoCut 3300 is designed to automatically cut all kinds of material, including wire, cable, tubing, flat ribbon, and glass fiber optic (GOF) cable. With its heavy-duty, precision cutting unit even very thin materials (Kevlar strand, foil, etc.) can be cut cleanly and square. This flexible machine can be used as a stand-alone unit or integrated into a processing line.The EcoCut 3300 is electronically controlled and features several interfaces for peripheral components. The electrically driven rollers feed the material in increments of 0.1 mm (0.004”) to the universal cutting unit. The cutting unit is electrically driven and position-controlled.
