| Wire outer diameter min. | 1.3 mm |
|---|---|
| Wire outer diameter max. | 12 mm |
| Embossing temperature min. | 50 °C |
| Stamping temperature max. | 200 °C |
| Connection options | An alle Komax Abläng-, Abisolier- und Crimpautomaten, sowie an die meisten Fremdfabrikate |
| Electrical connection | 230 V, 50/60 Hz (115 V, 50/60 Hz) |
| Compressed-air connection | 5 – 8 bar |
| Air consumption | 0.5 l/min |
| Weight | 18 kg |
| Weight of table | 42 kg |
| Dimensions/depth | 350 mm |
| Dimensions/width | 500 mm |
| Dimensions/height | 320 mm |
Komax 26
The Komax 26 hot-stamping printer has two manually adjustable stamping wheels, each with 16 characters, and prints wires from 1.3 to 6 mm outer diameter.
Thanks to the built-in standard input signal, the Komax 26 inkjet marker can be used on all standard wire processing machines. Wires can be printed efficiently and precisely with just two wire guides. An optimum marking result is achieved by adjusting the stamping force and temperature. Wire or film changes and text changes can be carried out without tools: The text to be printed is easily adjusted by turning the stamping wheels. The ribbons are also threaded in outside the machine, which is also possible during operation. This ensures short changeover times and high productivity.
