| Stripping range | 0.05 – 2.5 mm² (AWG 30 – 14) |
|---|---|
| Stripping length L | 3 – 20 mm (0.12 – 0.79 in.) |
| Pull-off length | 3 – 20 mm (0.12 – 0.79 in.) |
| Infeed length | 15 mm (0.59 in.) + L* |
| Cycle time approx. | 0.5 s |
| Power supply | 100 – 240 V, 50/60 Hz, 100 VA |
| Dimensions (W × D × H) | 190 × 295 × 190 mm (7.5 × 11.6 × 7.5 in.) |
| Weight | 7.5 kg (16.53 lbs) |
| Order specifications | V10AI000802 |
Bench Top
AI 02
The AI 2,5-20 auto is a stripping machine driven by an electric motor. It uses a system which detects the wire diameter and selects the cutting depth. Exact stripping of different insulated wires within the cross-section range of 0.5 up to 2.5 mm2 (AWG 20 – 14) is possible without an additional external adjustment. Stripping length and pull-off length are very easy to adjust.
